LC- XBM 31
XGA “Brilliant” Series
Easy Portable Projectors with life
long – life lamp ang long – life filter for eduction and business.
Outstanding Features :
► Brightnes 3.000 lumens
► Native XGA Resolution. WUXGA – VGA and
Mac Compatible
► Auto Setup (input search, V-keystone
correction, PC Adjust)
► Inexpensive projector with zoom lens
(x 1.2) and network monitoring and control
(Wired LAN)
► AC plug out right after Power off
and Direct off
► 20 languages (Operation menu)
► Black board (for green color) and
color board mode
► Lamp replacement on top cabinet
► Scurity : PIN code lock, Key lock
► Closed caption decoding ( NTSC)
► Control projector ( PC )
● Power ON
● Switch input
● Change Setup
● Chek the condition of projector 200 units are register-able (with PJ
Network
Manager)
► Control projector ( PJ )
Dending email to registered address
● Lamp is off
● Time for replace the lamp
● Signal is interrupted and etc.
10 e-mail address can be registered
Spesifikasi :
Screen Brightness ANSI : Ups to 3000 Lumens
Iluminattion Unifornity : 85%
Color Reproduction : 8-bit (16.7 million
colors)
Contrast Ratio : 2000 : 1 (High Lamp & Dinamic
Image & Iris On)
Projection Lamp : 215 W UHP
Estimated Lamp Lite : 6000/4000 H of use (eco /
Normal & High)
Imaging System : 0.63” (Polysicon active matrix TFT
Panels ) x 3”
Screen Pixels
(4:3 Aspect Ratio) : 1.024 x 768 in
stripe configuration
Total Pixels : 1.024 x 768 x 3
Lens :
F : 2.00 : 2.15 f : 18.38 ~ 22.06 mm ( 0.72 ~ 0.87 “ )
Zoom Ratios : 1.2 : 1
Throw Ratio : 1.43 ~ 1.72 : 1
Image Diagonal : 101 ~ 762 cm ( 40 ~ 300 in)
Image width : 0.81 ~ 6.1 m ( 2.7 ~ 20.0 ft )
Anti Keytone : Fixed Image offset. Ratio (Top
: Bottom ) 6 : 1
Throw Distance (wide-tele) : 1.1 ~ 10.5 m ( 3.50 ~ 34.4 ft)
Front Elevation : Up tp 10%
Projector Orentation : ± 30°
Vertical Keystone Correction : Vertical ± 30° ( Manual ) : ± 20° ( Auto)
Scanning Frequency : Auto H. Sync.15 ~100 kHz :
V Sync 50 ~ 100 Hz
Dot Clock : 140 MHz
Image Orientation : Normal, Reserved,
Inverted
Local Control : Full Function
Power Management : Auto Shutdown
Remote Projector Control :
Wireless (infra red) x 1
Control Port
(for RS-232-Control) : Dsub 9 pin x 1
Wire Network Port : LAN (RJ 45) x 1
Computer Native Resolution : 1.024 x 768 (XGA)
Computer :
- Compatibility : WUXGA, UXGA, SXGA+, SXGA. WXGA, XGA, SVGA,
VGA, Mac……. Analog⃰
- Format : 1.920 x 1.200 through 640 x 480
Video
- System
: NTSC, PAL ,
SECAM , NTSC 4.43, Pal – M&N
- HD
Compability : 1080i/50,
1080i/60, 1035i, 720p.
- SD
Compability : 575i,
575p, 480i, 480p
- Format
Supported : Normal 4:3 and wide screen 16 : 9
Image Connection :
- Computer
Input : D-sub 15x2
- Video
Input : RCA x 1
Monitor output : D-sub 15x1 Shared with input
Audio Connection :
- Audio
Input : Stereo
: mini jack x 1 (Shared with MIC input),
RCA R/L x 1
- Audio
Output : Stereo :
mini jack 1 (variable)
Audio Amplifier /
Built in Speaker : Mono : 10 W RMS
/ 3.7 cm (1.46 in) x 1 mono
Fan Noise : 29 dBA / 34 dBA / 36 dBA (
Eco/Normal/High)
Cabinet Dimension (HxWxD) : 104.6 x 333.5 x 247.0 mm (4.12 x 13.13 x
9.72 in)
Weight :
2.9 Kg ( 6.4 lb)
Packaged Dimension (HxWxD) : 210 x 418 x 398 mm (8.27 x 16.46 x 15.67 in)
Weight :
5.0 Kg ( 11 lb)
Power requirements : 100 ~ 240 V AC. 50 / 60
Hz
Power Compsumtion : 100V ~ 120 V : 286 W / 265
W . 195 W (High/Normal/Eco)
200V ~ 240 V : 271 W / 252 W / 187 W
(High/Normal/Eco)
Power Compsumtion : 100V ~ 120 V : 6.6 W / 0.4
W (Normal/Eco)
( Standby ) 200V ~ 240 V : 8.5 W / 0.7 W / 187 W
(Normal/Eco)
Power Cord : 3m (10”) Type 3, Detachable
Heat :
Up to 1067 BTU, H (267 Kcal.H)
Electrical Safety Compliance : UL, cUL, IEC
Electromagnetic Compability : FCC, ClassB, CE Mark
Operating Temperature : 5 ~ 35°C ( 41 ~ 95 F )
Include Accesoriess : Quick reference guide,
Ownwes manual ( CD-ROM).
CD- ROM read me note, PIN
Code label, UL Cable card,
Waranty card (for US), Net work Software
(CD-ROM),
AC Power cord, computer cable, remote
projector
control, Ferrite core, AAA battery x 2, Strap for lens cap,
lens cap, Filter cover for ceiling mount, S Video, D-sub
15, ( for US only).
Anda
berminat hubungi kami :
Contact
Person
Alat Peraga Pendidikan
Handphone
: 081288670484
Email : maidi_syahrial@ymail.com
Website
: http://dhita-lcd-catalog.blogspot.com
LC- XBL 26/21
XGA “Brilliat” Series
Simple and Easy Portable Projectors
Education use.
Outstanding Features :
► Brightnes 2.600 / 2.200 lumens with (
XBL26 / XBL 21 )
► True XGA Resolution. WUXGA – VGA and
Mac Compatible
► Longer Lamp Lite 6000 H ( Eco ) /
4000 H (Normal & High).
► Auto Setup (input search, V-keystone
correction, PC Adjust)
► Inexpensive projector with zoom lens
(x 1.2) and network monitoring and control
(Wired LAN)
► 1.0-watt Audio Speaker
► AC plug out right after Power off
► 20 languages (+Kazakh and
Vietnamese) <Operation menu>
► Black board (for green color) and
color board mode function
► Lamp replacement on top cabinet
► Scurity : PIN code lock, Key lock
► Closed caption decoding ( NTSC)
Network monitoring and Control
► Control projector ( PC )
● Power ON
● Switch input
● Change Setup
● Chek the condition of projector 200 units are register-able (with PJ
Network
Manager)
► Control projector ( PJ )
● Lamp is off
● Time for replace the lamp
● Signal is interrupted and etc.
10 e-mail address can be registered
Spesifikasi :
LC-XBL26
Screen Brightness ANSI : Ups to 2.600 Lumens (High Lamp
& Dinamic Image)
Iluminattion Unifornity : 85%
Size of Color Palette : 8-bit (16.7 million
colors)
Contrast Ratio : 500 : 1 (Full ON/OFF) <High
Lamp & Dinamic Image>
Projection Lamp : Up to 215 W UHP
Estimated Lamp Lite : up to 6000/4000 H of use (eco
/ Normal & High)
Imaging System : 0.55” Polysicon active matrix TFT
Panels x 3
Screen Pixels
(4:3 Aspect Ratio) : 1.024 x 768 in
stripe configuration
Total Pixels : 2.350.296 (< 1.024 x 768
> x 3 )
Lens Type : Manual
zoom and Focus
Lens Specs : F : 2.00 : 2.15 f : 0.724 –
0.869 in ( 18.38 – 22.06 mm )
Lens Ratios : Zoom 1.2 : 1 Throw , Width
1.62 – 1.92 : 1
Image Diagonal : 40 - 300 in ( 102 – 762 cm )
Image width : 2.65 – 20 ft ( 1.3 – 11.8 m )
Throw Distance (wide-tele) : 4.3 – 38.7 ft. 0.81 – 6.1 m )
Front Elevation/Maximum pitch : Up to 10° /+/- 30°
Anti Keytone :
Fixed Image offset. Ratio Top : Bottom ) 6 : 1
Vertical Keystone Correction : Auto +/- 20° Manual :+/- 30°
Scanning Frequency : Auto H. Sync.15 -100 kHz :
V Sync 50 – 100 Hz
Dot Clock : 140 MHz
Image Orientation : Normal, Reserved,
Inverted
Power Management : Auto Shutdown
Network Connection (LAN Port) : RJ 45 x 1
Remote Projector Control :
Wireless (infra red) x 1
Control Port
(for RS-232-Control) : Dsub 9 x 1
Computer Native Resolution : 1.024 x 768 (XGA)
Computer : Compatibility : WUXGA, UXGA, SXGA. WXGA, XGA, SVGA, VGA, Mac
Computer Format : 1.920
x 1.200 through 640 x 480
Computer : Higher Resolution : Displayed Panned or smart compressed
Computer : Low Resolution : Displayed Normal or Smart Expanded
Video Color System : NTSC / PAL / SECAM /NTSC
4.43 / Pal – M&N
Video Compability : SD : 480 i/p, 575
i/p, HD 720p, 1035i, 1080i 50/60
Video : Format Supported : Normal 4:3 and wide screen 16 : 9
Video Image Sizing : Video Scaling
Technology
Computer 1 Input or
Component ( Video / S-Video
Input Optional adapter : Dsub 15 x 1
Screen Brightness ANSI : Ups to 15000 Lumens (with AH-
22051)
Iluminattion Unifornity : 90%
Color Reproduction : 3000 : 1
Projection Lamp : 380 W NSHA x 4
Estimated Lamp Lite : 3000/2000 H (eco1.2 /
Normal mode)
Imaging System : 1.64” Inorganic Polysicon active
matrix TFT Panels x 3
Aspect Ratio : About 17 : 9
Total Pixels : 2048 x 1080 x 3
Lens :
Not Included- choose from aselection of optional lenses
Image Diagonal : 100 – 660 in ⃰¹
Image width : 2.21 – 13.26 m⃰¹
Throw Distance (wide-tele) : 5.8 – 48.0 m⃰¹
Front Elevation/Maximum pitch : 3” / 380” Pitch ( including normal, inverted,
up, down )
Keytone correction : Vertical ± 30°,
Hrizontal ± 30°
Scanning Frequency : Auto H. Sync.15 -120 kHz :
V Sync 48 – 120 kHz
Dot Clock : 230 MHz (Analog)
Image Orientation : Normal, Reserved,
Inverted
Wired/Wireless Network Port : RJ-45
Remote Projector /
Mouse Control : Wireless / normal x 1
Control Port(for RS-232-Control) : Dub
9 pin x 2(in / out)
Others :
Mini jack x 1 (for wired R/C)
Computer Native Resolution : 2048 x 1080
Computer : Compatibility : WUXGA⃰², UXGA⃰², WSXGA + SXGA +, SAGA, WXGA+,
WXGA, XGA, SVGA, VGA, Mac
Computer Format : 2048 x 1080 and 1920 x 1200 through 640
x 460
Lensa (Option) :
► Lensa Type On Axis Short Fixed
► Part No. AH-32022 (LNS-W03E)
► F value F 2.6
► Focal Length f = 30
► Image size ( inch ) 40 – 600
Slot Board (Option)
► Name DVI/D-sub 15 Board
► Part No. 72223 (PDA-AMD23ADI)
► Terminal DVI-D x1.D-sub 15x1
Terminal Remote Control
LC-HDT 2000
Auditorium Large Venue projector
Outstanding Features :
► Brightnes 15000 lumens with 4 lamp
mode. 3000 : 1 Contrast ratio
► Native 2K (2048 x 1080 ) Resolution.
2K – VGA and Mac Compatible
► “3 LCD+One” imaging system delivers
more sophisticated colr.
► Smoke Resistance Unit (Option)
► Active Maintenance Cleaner (AMC)
► Robust Design
► Hot Swappable Lamp System
► 10 bit color processing for superior
color reproduction
► Multi screen installation :
- Constant
brightnes function
- Color
matching function
- Edge
blending function
► Mechanical Schutter for true black
screen
► Picture in Picture for true black
screen
► Corner keystone correctton
► Optional Lens (11 types)
► Optional boards (4 types)
========================================================================
LC- XBL 26/21
XGA “Brilliat” Series
Simple and Easy Portable Projectors
Education use.
Outstanding Features :
► Brightnes 2.600 / 2.200 lumens with (
XBL26 / XBL 21 )
► True XGA Resolution. WUXGA – VGA and
Mac Compatible
► Longer Lamp Lite 6000 H ( Eco ) /
4000 H (Normal & High).
► Auto Setup (input search, V-keystone
correction, PC Adjust)
► Inexpensive projector with zoom lens
(x 1.2) and network monitoring and control
(Wired LAN)
► 1.0-watt Audio Speaker
► AC plug out right after Power off
► 20 languages (+Kazakh and
Vietnamese) <Operation menu>
► Black board (for green color) and
color board mode function
► Lamp replacement on top cabinet
► Scurity : PIN code lock, Key lock
► Closed caption decoding ( NTSC)
Network monitoring and Control
► Control projector ( PC )
● Power ON
● Switch input
● Change Setup
● Chek the condition of projector 200 units are register-able (with PJ
Network
Manager)
► Control projector ( PJ )
● Lamp is off
● Time for replace the lamp
● Signal is interrupted and etc.
10 e-mail address can be registered
Spesifikasi :
LC-XBL26
Screen Brightness ANSI : Ups to 2.600 Lumens (High Lamp
& Dinamic Image)
Iluminattion Unifornity : 85%
Size of Color Palette : 8-bit (16.7 million
colors)
Contrast Ratio : 500 : 1 (Full ON/OFF) <High
Lamp & Dinamic Image>
Projection Lamp : Up to 215 W UHP
Estimated Lamp Lite : up to 6000/4000 H of use (eco
/ Normal & High)
Imaging System : 0.55” Polysicon active matrix TFT
Panels x 3
Screen Pixels
(4:3 Aspect Ratio) : 1.024 x 768 in
stripe configuration
Total Pixels : 2.350.296 (< 1.024 x 768
> x 3 )
Lens Type : Manual
zoom and Focus
Lens Specs : F : 2.00 : 2.15 f : 0.724 –
0.869 in ( 18.38 – 22.06 mm )
Lens Ratios : Zoom 1.2 : 1 Throw , Width
1.62 – 1.92 : 1
Image Diagonal : 40 - 300 in ( 102 – 762 cm )
Image width : 2.65 – 20 ft ( 1.3 – 11.8 m )
Throw Distance (wide-tele) : 4.3 – 38.7 ft. 0.81 – 6.1 m )
Front Elevation/Maximum pitch : Up to 10° /+/- 30°
Anti Keytone :
Fixed Image offset. Ratio Top : Bottom ) 6 : 1
Vertical Keystone Correction : Auto +/- 20° Manual :+/- 30°
Scanning Frequency : Auto H. Sync.15 -100 kHz :
V Sync 50 – 100 Hz
Dot Clock : 140 MHz
Image Orientation : Normal, Reserved,
Inverted
Power Management : Auto Shutdown
Network Connection (LAN Port) : RJ 45 x 1
Remote Projector Control :
Wireless (infra red) x 1
Control Port
(for RS-232-Control) : Dsub 9 x 1
Computer Native Resolution : 1.024 x 768 (XGA)
Computer : Compatibility : WUXGA, UXGA, SXGA. WXGA, XGA, SVGA, VGA, Mac
Computer Format : 1.920
x 1.200 through 640 x 480
Computer : Higher Resolution : Displayed Panned or smart compressed
Computer : Low Resolution : Displayed Normal or Smart Expanded
Video Color System : NTSC / PAL / SECAM /NTSC
4.43 / Pal – M&N
Video Compability : SD : 480 i/p, 575
i/p, HD 720p, 1035i, 1080i 50/60
Video : Format Supported : Normal 4:3 and wide screen 16 : 9
Video Image Sizing : Video Scaling
Technology
Computer 1 Input or
Component ( Video / S-Video
Input Optional adapter : Dsub 15 x 1
====================================================
LC- XBL 21
XGA “Brilliant” Series
Simple and Easy Portable Projectors
Education use.
Outstanding Features :
► Brightnes 2.200 lumens with ( XBL26
/ XBL 21 )
► True XGA Resolution. WUXGA – VGA and
Mac Compatible
► Longer Lamp Lite 6000 H ( Eco ) /
4000 H (Normal & High).
► Auto Setup (input search, V-keystone
correction, PC Adjust)
► Inexpensive projector with zoom lens
(x 1.2) and network monitoring and control
(Wired LAN)
► 1.0-watt Audio Speaker
► AC plug out right after Power off
► 20 languages (+Kazakh and
Vietnamese) <Operation menu>
► Black board (for green color) and
color board mode function
► Lamp replacement on top cabinet
► Scurity : PIN code lock, Key lock
► Closed caption decoding ( NTSC)
Network monitoring and Control
► Control projector ( PC )
● Power ON
● Switch input
● Change Setup
● Chek the condition of projector 200 units are register-able (with PJ
Network
Manager)
► Control projector ( PJ )
● Lamp is off
● Time for replace the lamp
● Signal is interrupted and etc.
10 e-mail address can be registered
Spesifikasi :
LC-XBL26
Screen Brightness ANSI : Ups to 2.200 Lumens (High Lamp
& Dinamic Image)
Iluminattion Unifornity : 85%
Size of Color Palette : 8-bit (16.7 million
colors)
Contrast Ratio : 500 : 1 (Full ON/OFF) <High
Lamp & Dinamic Image>
Projection Lamp : Up to 215 W UHP
Estimated Lamp Lite : up to 6000/4000 H of use
(eco / Normal & High)
Imaging System : 0.55” Polysicon active matrix TFT
Panels x 3
Screen Pixels
(4:3 Aspect Ratio) : 1.024 x 768 in
stripe configuration
Total Pixels : 2.350.296 (< 1.024 x 768
> x 3 )
Lens Type : Manual
zoom and Focus
Lens Specs : F : 2.00 : 2.15 f : 0.724 –
0.869 in ( 18.38 – 22.06 mm )
Lens Ratios : Zoom 1.2 : 1 Throw , Width
1.62 – 1.92 : 1
Image Diagonal : 40 - 300 in ( 102 – 762 cm )
Image width : 2.65 – 20 ft ( 1.3 – 11.8 m )
Throw Distance (wide-tele) : 4.3 – 38.7 ft. 0.81 – 6.1 m )
Front Elevation/Maximum pitch : Up to 10° /+/- 30°
Anti Keytone : Fixed Image offset. Ratio Top :
Bottom ) 6 : 1
Vertical Keystone Correction : Auto +/- 20° Manual :+/- 30°
Scanning Frequency : Auto H. Sync.15 -100 kHz :
V Sync 50 – 100 Hz
Dot Clock : 140 MHz
Image Orientation : Normal, Reserved,
Inverted
Power Management : Auto Shutdown
Network Connection (LAN Port) : RJ 45 x 1
Remote Projector Control :
Wireless (infra red) x 1
Control Port
(for RS-232-Control) : Dsub 9 x 1
Computer Native Resolution : 1.024 x 768 (XGA)
Computer : Compatibility : WUXGA, UXGA, SXGA. WXGA, XGA, SVGA, VGA, Mac
Computer Format : 1.920 x 1.200 through 640 x 480
Computer : Higher Resolution : Displayed Panned or smart compressed
Computer : Low Resolution : Displayed Normal or Smart Expanded
Video Color System : NTSC / PAL / SECAM /NTSC
4.43 / Pal – M&N
Video Compability : SD : 480 i/p, 575
i/p, HD 720p, 1035i, 1080i 50/60
Video : Format Supported : Normal 4:3 and wide screen 16 : 9
Video Image Sizing : Video Scaling
Technology
Computer 1 Input or
Component ( Video / S-Video
Input Optional adapter : Dsub 15 x 1
LC- XL 100
XGA Boardroom Projector
User – Friendly Portable Projectors
with Easy maintenance and Cost-saving design.
Outstanding Features :
► Brightnes 6.000 lumens / 5.000 lumen
bright at 90% uniformity and a 1.000 : 1 contrast
ratio
► XGA Resolution. WUXGA – VGA and Mac
Compatible
► Inorganic imaging engine is optimized for extended use
► 10 bit color processing for superior
color reproduction
► Corner keystone correction function
► Vertical and horizontal lens shift
and 360° projector pitch
► Selft-advancing 10-exposure
cartridge air filter reduce maintenance
► Top-accessed lamp and filter make
maintenance easy
► Mechanical shutter for true black
screen no show
► Built-in RJ45 Wired Network
projector : Network monitoring & control
► Built-in 7-watt audio speaker
► Lensa (option)
► Terminal / Remote control
► Cabinet Size
Spesifikasi :
LC-XL 100
Screen Brightness ANSI : Ups to 5.000 Lumens
Iluminattion Unifornity : 90%
Size of Color Palette : 108-bit (1.07 billion
colors)
Contrast Ratio : up too 1000 : 1 (lamp control in
Auto mode)
Estimated Lamp Life : 3000 / 2000 hours of use
(eco/Normal mode)
Projection Lamp : 275 W NSHA
Imaging System : 0.8” Inorganic Polysicon active
matrix TFT Panels x 3
Screen Pixels : 1.024 x 768 in stripe
configuration
Total Pixels : 2.359.296 (< 1.024 x 768
> x 3 )
Lens :
F 1.7- 2.3, f : 1.05 – 1.78 in
(26.9-45.4 mm )
<with
AH-24741 lens>
Image Diagonal : Max 40 - 400 in ( 102 – 1.016 cm )
Image width : Max 2.65 – 26.67 ft ( 0.81 – 8.13
m )
Throw Distance (wide-tele) : 4.26 – 75.42 ft. ( 1.30 – 22.99 m )
<with AH-24741 lens>
Projector Elevation Adjustment:
Anti Keytone : Fixed Image offset. Ratio Top :
Bottom ) 6 : 1
Vertical Keystone Correction : Auto +/- 20° Manual :+/- 30°
Scanning Frequency : Auto H. Sync.15 -100 kHz :
V Sync 50 – 100 Hz
Dot Clock : 140 MHz
Image Orientation : Normal, Reserved,
Inverted
Power Management : Auto Shutdown
Network Connection (LAN Port) : RJ 45 x 1
Remote Projector Control :
Wireless (infra red) x 1
Control Port
(for RS-232-Control) : Dsub 9 x 1
Computer Native Resolution : 1.024 x 768 (XGA)
Computer : Compatibility : WUXGA, UXGA, SXGA. WXGA, XGA, SVGA, VGA, Mac
Computer Format : 1.920 x 1.200 through 640 x 480
Computer : Higher Resolution : Displayed Panned or smart compressed
Computer : Low Resolution : Displayed Normal or Smart Expanded
Video Color System : NTSC / PAL / SECAM /NTSC
4.43 / Pal – M&N
Video Compability : SD : 480 i/p, 575
i/p, HD 720p, 1035i, 1080i 50/60
Video : Format Supported : Normal 4:3 and wide screen 16 : 9
Video Image Sizing : Video Scaling
Technology
Computer 1 Input or
Component ( Video / S-Video
Input Optional adapter : Dsub 15 x 1
Anda
berminat hubungi kami :
Contact
Person
Alat Peraga Pendidikan
Handphone
: 081288670484
Email : maidi_syahrial@ymail.com
Anda
berminat hubungi kami :
Contact
Person
Maidi
Syahrial
Handphone
: 081288670484
Email : maidi_syahrial@ymail.com
